| उत्पत्ति के प्लेस | चीन |
| ब्रांड नाम | Hightop |
| प्रमाणन | CE，EPA，ISO，TUV |
| मॉडल संख्या | HT30 |
| Model | HT30 |
|---|---|
| Total Length | 4180mm |
| Total Width | 1500mm |
| Total Height | 2128mm |
| Ground Clearance | 458mm |
| Total Weight | 2600kg |
| Ground Pressure | 38kpa |
| Max. Digging Height | 3900mm |
| Max. Digging Radius | 4040mm |
| Max. Digging Depth | 2500mm |
| Max. Dumping Height | 2600mm |
| Slewing Angle | 360° |
| Grade Ability | 25° |
| Travel Speed | 2.6km/h |
| Bucket Capacity | 0.095m³ |
| Bucket Width | 500mm |
| Swing Angle of Boom | 70°/50° (L/R) |
| Track Gauge | 1150mm |
| Track Width | 250/260mm |
| Track Length (on ground) | 2300mm |
| Main Pump | Triple Pump |
| Main Pressure | 18Mpa |
| Max. RPM of the Pump | 2500r/min |
| Pump Displacement | 28ml/r |
